Hope-Wish develops cooled/uncooled IR lenses, thermal modules and night vision devices, with OEM & ODM available.
The HP-NM2011 multi-functional individual night vision monoculars support helmet mounting for hunting, and can connect to cameras for night shooting.
Place of Origin: China
Model Number: HP-NM2011
Minimum Order Quantity: 1 set
PRODUCT OVERVIEW
The HP-NM2011 multi-functional individual night vision monoculars support helmet mounting for hunting, and can connect to cameras for night shooting.
KEY FEATURES
Convertible monocular/binocular structure, supports helmet, weapon mount and night shooting function
Interchangeable objective lenses, optional 3x/5x/6x magnification
Optional long-range infrared illuminator for observation in total darkness
Ultra-broadband multi-layer anti-reflection coating for higher light transmission
Anti-glare protection plus built-in eyepiece indicators for better concealment
Optional IP68 rating, embedded spring battery cover and zero standby power consumption
TECHNICAL SPECIFICATIONS TABLE
|
Model |
HP-NM2011 |
|
Enhancement Tube |
2nd generation |
|
Resolution(lp/mm) |
48-65 |
|
Signal-to-noise Ratio(dB) |
17-21 |
|
Optical sensitivity (microampere/lumens) |
550-650 |
|
Trouble-free Time(h) |
10000 |
|
Magnification |
1x |
|
FOV |
40° |
|
Diopter Adjustment Range |
+5/-5 |
|
Lens system(mm) |
F1.2, 25.8 |
|
Objective Lens Adjustment Range |
0.25—∞ |
|
Volume(mm) |
142X73X55 |
|
Weight(g) |
385g |
|
Power Supply Voltage (v) |
2.0-4.2 |
|
Battery Type |
1X CR123A Lithium Battery |
|
Continuous working time (h) |
80（Without Infrared） |
|
40（Infrared） |
|
|
Operational temp. (°C ) |
-40/+60 (°C ) |
|
Dustproof and Waterproof Grade |
IP68 |
Structure Name
CUSTOMIZATION OPTIONS
Optical customization
Adjust magnification, objective aperture, light transmittance and image intensifier parameters.
Structural customization
Modify body size, interface type, IP rating and ergonomic structure.
Function customization
Customize brightness threshold, auto-protection parameters and intelligent sensing settings.
Accessory customization
Match infrared intensifier, sight bracket, eyecup and adaptive functional accessories.
Software customization
Customize display parameters, device protocols and supporting operation manuals.
Brand customization
Custom logo, neutral packaging and personalized product documentation.
OEM & ODM full development
Exclusive structural design and customized functional integration solutions.
APPLICATION
Night patrol
Night hunting
Outdoor field exploration
Field search, rescue
